Power Control Cables

Power & Control Cables

EIS Wire & Cable manufactures a variety of high performance power and control cables for use in the industrial distribution market. Our cables offer superior features in design and approvals that make them an excellent choice for markets such as: Power generation, Refining and Petrochemical, Steel, Pulp and Paper, Solar, Factory Automation and Mining.

Instrument / Power-Limited Tray Cables

Instrument and control wiring designed for use in factory automation equipment, material handling, sensors, process control and other application where high reliability and installation consideration is essential.

  • Type ITC/PLTC General Purpose Tray Cable (300 volts)
  • -30°C +105°C rated
  • Sunlight resistant; suitable for outdoor use.
Standards

  • NEC Articles 727 & 725
  • UL 2250 ITC (22AWG – 12AWG)
  • UL 13 PLTC
  • UL 1685 flame test
  • IEEE 1202 / FT4

Additional available ratings:

  • UL AWM 2517 (300V)
  • UL AWM 2586 (600V)
  • AWM l/ll A/B 300V FT4
  • AWM l/ll A/B 600V FT4
  • CMX-OUTDOOR-CMG
  • MSHA

Unshielded Multi-Conductor Cables Construction

Conductors22AWG – 16AWG, Tinned Copper. Additional gauge sizes and custom conductor count (2 to 30) available upon request.
InsulationExtruded PVC/Semi-Rigid PVC
JacketExtruded Black PVC. Additional colors are available upon customer request.
Color CodeIndividually colored for ease of identification.
UNSHIELDED
AWG (Strand)# Cond.Nom. Jkt Thickness (Inches)Nom. Insul. (Inches)Nom. O.D. (Inches)Wt./ MFT (Lbs.)VoltageTempTypeColor Code Chart K2
22 (7/30)2.035”.013”.190”17.4300105ºCPLTC/ITC/CL3Black, White
22 (7/30)3.035”.013”.199”21.1300105ºCPLTC/ ITC/CL3Black, White, Red
22 (7/30)4.035”.013”.214”25.4300105ºCPLTC/ ITC/CL3Black, White, Red, Green
20 (7/28)2.035”.013”.206”21.9300105ºCPLTC/ITC/CL3Black ,White
20 (7/28)3.035”.013”.216”27.6300105ºCPLTC/ITC/CL3Black, White, Red
20 (7/28)4.035”.013”.233”33.6300105ºCPLTC/ITC/CL3Black, White, Red, Green
18 (7/.0152)2.035”.015”.236”28.6300105ºCPLTC/ITC/CL3Black, White
18 (7/.0152)3.035”.015”.249”36.6300105ºCPLTC/ITC/CL3Black, White, Red
18 (7/.0152)4.035”.015”.269”44.6300105ºCPLTC/ITC/CL3Black, White, Red, Green

Shielded Multi-Conductor Cables Construction

Conductors22AWG – 16AWG, Tinned Copper. Additional gauge sizes and custom conductor count (2 to 30) available upon request.
InsulationExtruded PVC/Semi-Rigid PVC
ShieldAluminum/Polyester foil overall. Optional braided shield available upon request.
JacketExtruded Black PVC. Additional colors are available upon customer request.
Color CodeIndividually colored for ease of identification.
SHIELDED
AWG (Strand)# Cond.Nom. Jkt Thickness (Inches)Nom. Insul. (Inches)Nom. O.D. (Inches)Wt./ MFT (Lbs.)VoltageTempTypeColor Code Chart K2
22 (7/30)2.035”.013”.190”18.8300105ºCPLTC/ITC/CL3Black, White
22 (7/30)3.035”.013”.199”22.5300105ºCPLTC/ ITC/CL3Black, White, Red
22 (7/30)4.035”.013”.241”26.8300105ºCPLTC/ ITC/CL3Black, White, Red, Green
20 (7/28)2.035”.013”.206”23.9300105ºCPLTC/ITC/CL3Black ,White
20 (7/28)3.035”.013”.216”29.6300105ºCPLTC/ITC/CL3Black, White, Red
20 (7/28)4.035”.013”.233”35.6300105ºCPLTC/ITC/CL3Black, White, Red, Green
18 (7/.0152)2.035”.015”.236”30.6300105ºCPLTC/ITC/CL3Black, White
18 (7/.0152)3.035”.015”.249”38.6300105ºCPLTC/ITC/CL3Black, White, Red
18 (7/.0152)4.035”.015”.269”46.6300105ºCPLTC/ITC/CL3Black, White, Red, Green
